Phenyl glycidyl ether Molecule 3D Model with Engraved Atoms - Chemistry Teaching Aid (CAS 122-60-1)

Phenyl glycidyl ether molecular model (C9H10O2, CAS 122-60-1): a free, print-ready ball-and-stick model with the element symbol engraved on every atom, designed for chemistry lessons.

Let the group sketch what they see in Phenyl glycidyl ether, namely two rings (one 3-membered and one 6-membered), one of them aromatic; afterwards they compare the sketch with the 22 bonds on the model (16 single and 6 aromatic, drawn in Kekulé form). A five-minute warm-up: read the symbol on every sphere and write down the totals (9 C + 10 H + 2 O = 21 atoms). Teachers covering aromaticity and delocalised electrons, chirality, enantiomers and CIP (R/S) rules, as well as ring strain in three-membered rings will find it a concrete example. Team task: with the model in hand, each group marks the epoxide ring (three-membered C-O-C ring) and the ether linkage (C-O-C), then writes down what they found. Phenyl glycidyl ether brings one stereocentre without an assigned R/S label: a good prompt for discussing enantiomers.

Printing: the STL is in angstrom units - scale it 10x in the slicer (1 angstrom = 10 mm). Use supports under the bonds; PLA works well.

Full data, safety notes and other formats: https://molgod.org/molecule/122-60-1/

Licence and provenance: https://molgod.org/licenses/stl/122-60-1/

MolGod ID: MG_496-573-404-66

Also published on: NIH 3D https://3d.nih.gov/entries/3DPX-023734 · Zenodo (DOI, latest version) https://doi.org/10.5281/zenodo.23296338 · Figshare (dataset DOI) https://doi.org/10.6084/m9.figshare.34425396

Atomic coordinates: PubChem computed 3D conformer; mesh generated by MolGod's own software. Licence: CC BY-SA 4.0, MolGod.org.
